Project Description
A customer in the digital communications industry contracted us to create the corrugated horn highlighted here.
Utilized in a communications device, this part was composed of aluminum, and expertly manipulated with our advanced CNC turning and milling processes. This is a prime example of our external and internal precision lathe work capabilities, machining the part while maintaining a tight tolerance throughout. The machined unit was subjected to a deburring treatment for cleaning and smoothing, and then anodized to a yellow Iridite finish. Integrity and quality were ensured with comprehensive visual and dimensional inspections.
Completed dimensions of the part were 6″ x 14″, executed according to customer supplied CAD drawings. Turnaround time for this project was 4 to 8 days, producing 4 pieces for the customer in California.
For more details about this segment number 3 corrugated horn fabrication, or the other precision fabrication and industrial contracting capabilities available, please see the table below or contact us directly.
Project Highlights
Communications device
Capabilities Applied/Processes
Primary:
CNC Turning
CNC Milling
Secondary:
Deburring
Anodizing
Equipment Used to Manufacture Part
CNC Lathes, CNC Milling Machines
Overall Dimensions
6″ x 14″
Materials Used
Aluminum
Material Finish
Anodized – Yellow Iridite
In process testing/inspection performed
Dimensional Inspection, Visual Inspection
Industry for Use
Digital Communications
Volumne
4 pcs
Delivery/Turnaround Time
4-8 days
Delivery Location
California
Standards Met
Customer Specifications, CAD Drawings
Product Name
Segment No.3 Corrugated Horn
